Quick Details

  • Place of Origin: Henan, China (Mainland)
  • Brand Name: Huadong
  • Model Number: Overhead Cable
  • Insulation Material: XLPE
  • Type: Low voltage
  • Application: Overhead
  • Conductor Material: Aluminum
  • Jacket: no jacket
  • conductor: aluminum
  • core: duplex/triplex/quadruplex
  • voltage: low voltage
  • application: overhead
  • Standard: IEC
  • Conductor: strand
  • stock: in stock
  • delivery: on time
  • sample: free sample
  • item name: 3*35+16mm ABC Overhead Cable

Packaging & Delivery

Packaging Details LV AAC conductor triplex SERVICE XLPE Overhead cable 3*35+16mm ABC Overhead Cable packing is :
1) Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement
2) Outer packing: wooden case, carton box
3) Other packing requirement according to client's request.
Delivery Time 7 days after received your deposit.
LV AAC conductor triplex SERVICE XLPE Overhead cable 3*35+16mm ABC Overhead Cable.
Product Description
Item name: LV AAC conductor triplex SERVICE XLPE Overhead cable 3*35+16mm ABC Overhead Cable.

1,0.6/1KV. Rated voltage: Up to and including 0.6/1(1.2)kV;
2. Conductor: Pure annealed copper or aluminum.
3. Insulation: XLPE/PE/PVC.
4. Cores: 1 C, 2C, 3C, 4C.
5. Nominal Cross-section: 10mm2 to 400mm2.
6. Standard: GB/T 14049-2008 IEC 60502.
7. Max. Operating Temperature: XLPE/PE: 90 °C , PVC : 70 °C .
8. Type: ABC Cable, JKTRYJ, JKLYJ,JKTRY, JKLY, JKLGYJ, JKLGY, JKLYJ/Q, JKLY/Q, JKLGYJ/Q, JKLGY/Q.
9.Packing: Wooden Drum or according to the customer requirement.
10.Remark: The cable can be of flame retardant, fire resistance and other property.

Overhead cable.

For single core PVC or XLPE insulated or covered aerial cable without messenger or neutral conductor,
the phase conductor may be AAC or AAAC or ACSR or Copper.



For more than one core PVC or XLPE insulated 11kv abc cable with or without messenger or neutral conductor and with or without street lighting conductor, the phase conductor and street lighting conductor are AAC with PVC insulation,and the messenger or neutral conductor is AAAC or ACSR with or without



temperature of conductor during short-circuit ( 5s max. duration) shall not exceed: 250oC(XLPE insulated), 130 oC (PE insulated), 160 oC (PVC insulated); 11kv abc cable The ambient temperature under installation should not be lower than: -20 oC.



Application of Overhead abc cable.

PVC or XLPE insulated 11kv abc cable as a new-type aerial cable is used for overhead electric power transmission,
extensively used in rebuilding of urban and forest region electrified wire netting. It improves the safety and reliance of electrified wire netting.



1. LV AAC conductor triplex SERVICE XLPE Overhead cable 3*35+16mm ABC Overhead Cable Construction.

Code*WordPhase conductorBare Neutral MessageNominal lay LengthWeight Per
1000 ft.(lbs.)
Allo wable Amp acitles
Size
(A WG)
StrandingInsul
Thick(Mils)
Size
(AWG)
StrandingRated
Strength
(lbs.)
inchesXLPPOLYXLPPOLY
AAC Neutral-messenger
Pekingese61456756310.3661618570
Collie67456756310.3664648570
Dachshund41454788110.36929211590
Spaniel47454788110.36969611590
Doberman274527135014.88147147150120
Malemute1/09601/07199014.88234234205160



LV AAC conductor triplex SERVICE XLPE Overhead cable 3*35+16mm ABC Overhead Cable. .

a.Application

Used to supply 3-phase power,usually from a pole-mounted transformer,to the user's service head where connection to the service entrance cable is made.To be used at voltage of 600 volts phase-to-phase or less and at conductor temperature not to exceed 75 for polyethylene insulated conductors or 90 for crosslinked polyethylene(XLP) insulated conductors.
b.Construction

Code*WordPhase conductorBare Neutral MessageNominal lay LengthWeight Per
1000 ft.(lbs.)
Allo wable Amp acitles
Size
(A WG)
StrandingInsul
Thick(Mils)
Size
(AWG)
StrandingRated
Strength
(lbs.)
inchesXLPPOLYXLPPOLY
AAC Neutral-messenger
Clydessdale41454788120.5819819810080
Pinto47454788120.5821121110080
Mustang274527135025.42318318135105
Criollo1/09601/07199025.42503503180140
Percheron2/011602/07251029.97619619205160
Hanovarian3/017603/019331035.18764764235185
Oldenburg4/018604/019402035.18945945275210
Lippizaner336.41980336.419614638.7915191519370280




Packaging & Shipping
LV AAC conductor triplex SERVICE XLPE Overhead cable 3*35+16mm ABC Overhead Cable.

1) Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement.
2) Outer packing: wooden case, carton box.
3) Other packing requirement according to client's request.

Our Services

LV AAC conductor triplex SERVICE XLPE Overhead cable 3*35+16mm ABC Overhead Cable.

1. We guarantee to offer new advanced goods.

2. We'd like to send skilled personnel to the installing place to help offer technical consultant, quantity estimation and instruction, installing, preliminary testing,and help start up running; and to answer for any defect of the product found in installing and run testing, If there's something wrong with the product, we'll give our answer within 12 hours and get to the spot within 36 hours.

3.After installaton,We'll send skilled personnel to have the preliminary test and answer for any problems emerged. We take the whole charge of the fee needed in repairing,testing or retesting within the scope of our duty required in contract.

4.During the contract's period of validity,of the project must be started all over again or the goods can not be used at all which is resulted from our faulty goods and improper files or mistakes made by our instructors, we'll change the goods at once without compensation and take charge in all expenses of reinstallation.

Company Information

Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production, research & development,and domestic& international trade.

Established year: 1988

Total asset: USD 32 million

Plant area: 30000 m2

Number of staff: 380

Engineer:20

Laboratory Inspector: 18

Production line: 18

Testing machine:25

Producing capacity each year: 320000 km.

LV AAC conductor triplex SERVICE XLPE Overhead cable 3*35+16mm ABC Overhead Cable Standard:

Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on. Meanwhile we  can produce based on customers' requirements and specifications.

LV AAC conductor triplex SERVICE XLPE Overhead cable 3*35+16mm ABC Overhead Cable Certificate:

The company has passed ISO90012008 quality certification, CCC China Compulsory Certification, National Electrical Product Safety  Certification, State Construction and ProjectCommitee Recommended Manufacturer of the Transformation of Urban and Rural Power Grid Construction.

FAQ

1.what is our payment term ?

  Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?

  The lead time usually is 10 - 30 working days.

3.what is the package of the cable ?

  The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?

  Sure, we provide the free sample for customer to checking.
